1.Regulative cutting speed, the user can adjust various cutting speeds according to different fabrics.
2.It is attached with a special air-floated blowing device to reduce the excess resistance formed between the cutting sheet weight and cutting table.
3.It makes easy move for cutting sheet and more precise cutting for small cutting sheets.
4.Extremely easy cutter removal & replace.
5.It is attached with a grinding device to ensure constant sharp of the cutter.
6.Could be choose the belt safety protection device.
7.Tool for blade grinding equipped in machine.
8.Powerful blowing motor for air flow to cutting table which makes fabric moving easier.
9.Applicable for cutting Curved Shapes, Round Shapes & other cutting needs for fabric.
|
Model |
AS-900A/B |
AS-1200A/B |
|
Table Specification(mm) |
1500x1800 |
1500x2400 |
|
Cutting Height (mm) |
180 |
250 |
|
Knife Span(mm) |
900 |
1200 |
|
Knife Size(mm) |
0.45x10x3860 |
0.45x10x3860 |
|
Voltage(V) |
220/380V |
220/380V |
|
Net Weight(kgs) |
185 |
330 |
|
Packing Size(mm) |
1920x830x1800 |
1920x830x1800 |
