1.Cycled 9 Pair of Electro Magnetic Coil, Dual-frequency integrated circuit, cross magnetic induction detection, bring with higher accuracy, reliability and stability.
2.Equipped with Automatic control system and uses special magnetic sensitive materials and unique technology, the detection accuracy of the needle detector is particularly high, and the exact needle-breaking position is displayed into detection zone.
3. Detection Sensitivity can be adjusted and real-time signal display.
4.Photo sensors to detect and count number of items.
5. Eco friendly Seamless Conveyor Belt material ensures safety to environment.
6.Automatic detection, automatic induction, automatic stop when no detection is needed, 0-10 sensitivity degree adjustment, when there is a broken needle, the conveyor belt automatically stops and returns backwards.
7.With counting function, it can count the number of qualified or defective products.
8.It has three alarm modes: sound effect, light alarming & Conveyor Belt return or Stop.
|
Model |
AS-770CE-100 |
AS-770CE-200 |
AS-770CE-300 |
|
Detection method |
Magnetic induction |
Magnetic induction |
Magnetic induction |
|
Sensitivity adjustment |
1-10 Degree |
1-10 Degree |
1-10 Degree |
|
Detection sensitivity |
0.8/1.0 mm Iron Ball |
1.5 mm Iron Ball |
2.5 mm Iron Ball |
|
Alarm method |
Beep, Light, Belt Stop |
Beep, Light, Belt Stop |
Beep, Light, Belt Stop |
|
Detection width |
600mm |
600mm |
600mm |
|
Detection height |
100mm |
200mm |
300mm |
|
Power supply |
220V 50Hz |
220V 50Hz |
220V 50Hz |
|
Power consumption |
120W |
120W |
120W |
|
Weight |
250kg |
280Kg |
320Kg |
|
Dimension(L×W×H) |
1600*1050*950mm |
1600*1050*1060mm |
1600*1050*1160mm |
