1.Double Head, Double sensor, ensures high accuracy detection in garments, shoes, bags etc..
2.Imroved coil sensitivity, strong magnetic induction, strong anti-interference technology.
3.LED display panel, smart counter ,exact locating of broken needles through detection zone.
4.Branded computer chip, dual-frequency integrated circuit, cross magnetic induction detection, bring with higher accuracy, reliability and stability.
5.Automatic control system uses special magnetic sensitive materials and unique technology, the detection accuracy of the needle detector is particularly high, and the exact needle-breaking position.
6.Twin search heads design, double detection function, higher safety performance, compared with other types of needle detectors, at the same detection height, the sensitivity is increased by 10%.
7.Automatic detection, automatic induction, automatic stop when no detection is needed, 0-10 sensitivity degree adjustment, when there is a broken needle, the conveyor belt automatically stops and returns backwards.
8.With counting function, it can count the number of qualified or defective products.
9.It has three alarm modes: sound effect, light alarming & Belt Stops.
10.Luxury appearance, novel style, saving time and electricity, simple operation
|
Model |
AS-760CE-2C-100 |
AS-760CE-2C-150 |
AS-760CE-2C-200 |
|
Detection Method |
Electromagnetic Induction |
Electromagnetic Induction |
Electromagnetic Induction |
|
Detection Width |
600mm |
600mm |
600mm |
|
Detection Height |
100mm |
150mm |
200mm |
|
Detection Capability |
Fe 0.8/1.0 |
Fe 1.2/1.5mm |
Fe 1.5/2.0mm |
|
Alarm Mode |
Beep, LED Light, Belt Stop |
Beep, LED Light, Belt Stop |
Beep, LED Light, Belt Stop |
|
Sensitivity Adjustment |
1-10 Level |
1-10 Level |
1-10 Level |
|
Conveyor Speed |
30mtr/min. |
30mtr/min. |
30mtr/min. |
|
Voltage & Frequency |
220V 50-60Hz |
220V 50-60Hz |
220V 50-60Hz |
|
Power |
120W |
120W |
120W |
|
Dimension(L*W*H) |
2350*1150*950mm |
2350*1150*1010mm |
2350*1150*1060mm |
|
Weight |
320Kg |
380Kg |
430Kg |
