Technical Parameters
|
Model |
AS-6040L |
AS-9060L |
AS-1210L |
AS-1610L |
||
|
Engraving Area/Cutting Area |
600x400mm |
900x600mm |
1200x1000mm |
1600x1000mm |
||
|
Laser power |
60w/80w/100w/150w/180w |
|||||
|
Laser Type |
Sealed CO2 Glass Laser Tube |
|||||
|
Engraving speed |
0~1500mm/s |
|||||
|
Cutting speed |
0~400mm/s |
|||||
|
Resetting positioning accuracy |
<0.05mm |
|||||
|
Cutting depth |
0-20mm(Cutting depths depends on materials) |
|||||
|
Minimum Shaping Character |
1x1mm |
|||||
|
Working Voltage |
220V/110V ±10% Single Phase |
|||||
|
Machine whole power |
2500W |
|||||
|
Control system |
Ruida (U disk, Offline support) |
|||||
|
Software supported |
Light Burn, CorelDraw, Photoshop, AutoCAD |
|||||
|
Graphic format supported |
PLT,DXF,BMP,JPG,GIF,PGN,TIF |
|||||
|
Engraver for Curve surfaces (Yes/No) |
Rotary Device Required (Optional) |
|||||
|
Water Cooling(Yes/No) |
Yes |
|||||
|
Laser Tube (Life hours) |
8,000-10,000 hours |
|||||
|
Assistant Equipment |
Water Chiller |
Exhaust Fan |
Air Pump |
|||
